Piling Kit for Excavators
We can convert your excavator into a complete rotary drilling rig, which can make the drilling and piling works in ultra limited space conditions - inside rooms and buildings, under the electric lines, in mountains, in small yards, under the briges, on slopes and so on.
For excavators from 2,3 tons
Robust Construction 🛡
Made from high-strength materials to withstand intense use and harsh conditions
Versatile Application 🚜
Ideal for a wide range of projects, including foundations, retaining walls, and utility installations
Easy Installation 🛠
Quick and simple attachment process, allowing you to switch tasks effortlessly
Enhanced Precision 📐
Engineered for accurate piling, ensuring maximum stability and support for your structures
Increased Productivity 📈
Optimize your workflow and reduce project timelines with our reliable piling solution
Made from high-strength materials to withstand intense use and harsh conditions
Versatile Application 🚜
Ideal for a wide range of projects, including foundations, retaining walls, and utility installations
Easy Installation 🛠
Quick and simple attachment process, allowing you to switch tasks effortlessly
Enhanced Precision 📐
Engineered for accurate piling, ensuring maximum stability and support for your structures
Increased Productivity 📈
Optimize your workflow and reduce project timelines with our reliable piling solution
Features
Drilling Depth Standard 2 mt Kelly: 10 mt/32,8 ft
Drilling Depth Standard 2.5 mt Kelly: 13 mt/42,65 ft
Max Drilling Diameter: 600 mm/23,62 in
Telescopic Standard Kelly Bar: 6 elem mt/2x6 elem ft
Drilling Depth Standard 2.5 mt Kelly: 13 mt/42,65 ft
Max Drilling Diameter: 600 mm/23,62 in
Telescopic Standard Kelly Bar: 6 elem mt/2x6 elem ft
Max Line Pull @ 220 Bar: 9 KN/2023,28 lbs
Max Line speed/Variable: 65 mt/min/213,25 ft/min
Rope Diam: 10 mm/0,31 in
Drum Capacity First Layer: 10 mt/32,8 ft
Rope Capacity: 50 mt/164,04 ft
Inletting Flow: 35 lt/9,24 Gal
Max Line speed/Variable: 65 mt/min/213,25 ft/min
Rope Diam: 10 mm/0,31 in
Drum Capacity First Layer: 10 mt/32,8 ft
Rope Capacity: 50 mt/164,04 ft
Inletting Flow: 35 lt/9,24 Gal
Max Line Pull: 4 KN/899,23 lbs
Max Line speed: 50 Mt/Min/164,04 ft/Min
Rope Diam: 8 mm/ 3/4 in
Drum Capacity First Layer: 10 mt/32,8 ft
Max Line speed: 50 Mt/Min/164,04 ft/Min
Rope Diam: 8 mm/ 3/4 in
Drum Capacity First Layer: 10 mt/32,8 ft
Rotary Torque @ 320 Bar: 5 KNm @ 20 Rpm/3687,8 lb ft @ 20 Rpm
Working Speed I° Gear: 20 Rpm
Working Speed I° Gear: 110 Rpm
Working Speed I° Gear: 20 Rpm
Working Speed I° Gear: 110 Rpm
Rotary Pull Down Capacity: 9,5 KN @ 200 Bar/2135,68 lbs @ 200 Bar
Rotary Lifting: 5 KN @ 200 Bar/1124,04 lbs @ 200 Bar
Hydraulic Jack Stroke: 600 mm/23,62 in
Rotary Lifting: 5 KN @ 200 Bar/1124,04 lbs @ 200 Bar
Hydraulic Jack Stroke: 600 mm/23,62 in
KIT Weight in Working Conditions: 430 RG/944,19 lbs
